Plaster acoustic ceiling tiles are manufactured from reinforced casting plaster and offer excellent sound absorption, controlled sound transmission and decorative finishes. The tiles are supplied with an integrated sound absorbent batt inserted during casting and are produced in a range of varying designs. These tiles are pre-painted white.

Advantages

1. Dimensionally stable will not warp or buckle
2. Not affected by humidity
3. Fire resistant
4. Acoustic properties
5. Redecoration does not affect the properties
6. Easy removal and replacement

To be used in conjuction with exposed ceiling grid: 24 mm T Bar steel or aluminum 600 x 600 system.

Product Specifications

Tile Name: Shadex

Collection: Lightweight

Thickness (mm): 30

Size(mm): 600 x 600

CAC: 32/36¹ 32/36²

R Value: 0.80

NRC: 0.70¹ 0.65²

% light reflective: 0.73

Mass (Kg/sqm):12.20

Edge Finish: Bevelled

Fixing: Exposed Grid

Fiberglass insulation batt – 32Kg/cu.m, 20mm thick Glasswool/Polyester
¹Glasswool ²Polyester – further test pending
